PULSAR-XTX

Space Transmitter by AAC Clyde Space (2 more products)
Download Datasheet Request Information

Note : Your request will be directed to AAC Clyde Space.

The PULSAR-XTX from AAC Clyde Space is a Space Transmitter with Mass 130 g, Frequency Range 8.025 to 8.375 GHz, Data Rate 10 to 50 Mbps, RF Output Power 33 dBm, Spurious Response -60 dBc. More details for PULSAR-XTX can be seen below.

Product Specifications

Product Details

  • Part Number
    PULSAR-XTX
  • Manufacturer
    AAC Clyde Space

General Parameters

  • Space Heritage
    Yes
  • Satellite Type
    CubeSat
  • Band
    X Band
  • Mass
    130 g
  • Frequency Range
    8.025 to 8.375 GHz
  • Data Rate
    10 to 50 Mbps
  • RF Output Power
    33 dBm
  • Modulation Format
    OQPSK, QPSK, CCSDS, SFCG 21-2R4
  • Spurious Response
    -60 dBc
  • Supply Voltage
    6.2 to 17 V
  • Power Consumption
    15 W
  • Interface
    SPI
  • Operating Temperature
    -25 to 61 Degree C
  • Connector
    SMP
  • Dimension
    96 x 90 x 11.7 mm(L x W x H)
  • Note
    Impedance : 50 Ohms

Technical Documents
