5 V, 1 A, Buck/Step down DC to DC Converter

SKU: MGA2805S

Download Datasheet Request Information

Note : Your request will be directed to Crane Aerospace & Electronics.

MGA2805S Image

The MGA2805S from Crane Aerospace & Electronics is a DC to DC Converter with Input Voltage 16 to 40 V, Output Voltage 1 5 V, Output Current 1 1 A, Output Power 5000 mW, Isolation Voltage 500 Vdc. Tags: Module, Buck/Step down. More details for MGA2805S can be seen below.

Product Specifications

Product Details

  • Part Number
    MGA2805S
  • Manufacturer
    Crane Aerospace & Electronics
  • Description
    5 V, 1 A, Buck/Step down DC to DC Converter

General Parameters

  • Segment
    Satellite
  • Type
    Buck/Step down
  • Configuration
    Isolated
  • Number of Output
    Single
  • Input Voltage
    16 to 40 V
  • Output Voltage 1
    5 V
  • Output Current 1
    1 A
  • Output Power
    5000 mW
  • Isolation Voltage
    500 Vdc
  • Efficiency
    0.71
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Module
  • Application
    Aerospace
  • Dimension
    28.19 × 28.19 × 6.35 mm
  • Capacitance
    300 uF
  • Regulation
    10 to 50 mV (Line), 10 to 50 mV (Load)
  • Ripple Voltage
    125 to 525 mVpp
  • Storage Temperature
    -65 to 150 Degree C
