The MFK282R5S from Crane Aerospace & Electronics is a DC to DC Converter with an input voltage range of 16-50 V an output voltage of 2.5 V. It has an output current of 5 A and an output power of up to 12.5W. The MFL converter is manufactured in a fully certified and qualified MIL-PRF-38534 facility and has an efficiency of up to 87%. It has a line regulation range of 5-20 mV and a load regulation range of 5-25 mV. This converter has a capacitance of 2000 µF and a ripple voltage of 30-80 mVpp. It uses a synchronization feature that is included with the converter that allows the user to match the switching frequency of the converter to the frequency of a system clock. The converter has an undervoltage lockout, fully isolated magnetic feedback with in-built short circuit protection. It weighs 38 grams and measures 37.08 × 28.70 × 9.14 mm in dimension. The converter is ideal for use in programs requiring high reliability, small size, and high efficiency.
