5.6-330 µF Solid Tantalum MnO2 Capacitor

SKU: CTC21

Space Qualified Capacitor by Exxelia Technologies (6 more products)
Download Datasheet Request Information

Note : Your request will be directed to Exxelia Technologies.

CTC21 Image

The CTC21 from Exxelia Technologies is a Space Qualified Capacitor with a capacitance range of 5.6-330µF. It requires a voltage of 6.3 to 63 V and has a tolerance of ±10% to ±20%. This capacitor has a maximum leakage current of 7.6 to 173 µA and a maximum reverse voltage of 1-10 % UR (125-20°C). It has an operating temperature of –55°C to +125°C and measures 11 x 12.5 x 5.5 mm.

Product Specifications

Product Details

  • Part Number
    CTC21
  • Manufacturer
    Exxelia Technologies
  • Description
    5.6-330 µF Solid Tantalum MnO2 Capacitor

General Parameters

  • Capacitor Type
    Solid Tantalum Capacitor
  • Space Standard
    ESCC 3012/002, ESA-ESCC EPPL 1
  • Capacitance
    0.0000056 to 0.000330 F
  • Voltage
    6.3 to 63 V
  • Tolerance
    ±10%, ±20%
  • Reverse Voltage
    1 to 10 % UR
  • Operating Temperature
    -55 to 125 Degree C
  • Package Type
    Surface Mount
  • RoHS Complaint
    Yes
  • Dimension
    11 x 12.5 x 5.5 mm (L x W x H)
